NEJE A40630 7.5W 450nm Laser Engraver Module Kits
Highlights

1.Designed for laser engraver, 3D printer, CNC mill, arduino project.
7.5W Optical power output, 4mm plywood from 1 pass (speed 100).
More Safety, Built-in protective glass to protect eyes! Even without wearing protective glasses, the operation is more comfortable.
More Quiet, Intelligent drive adjust the cooling fan speed according to laser temperature.
Easy use, Digital PWM wave pulse signal generator adjustable frequency duty cycle board for NEJE laser module.
The slidable mounting fixture is provided for easy adjustment of focus.
2 in 1 lens, adjustable focus and fixed focal length in one module.

Specification
Heatsink Material: Aircraft Aluminum + Brass Shell
2. Luminous Color: Blue
Section Size: 40mm x 40mm
Cooling Mode: Temperature sensor intelligent control + 10000 rpm 40mm cooling fan
Dimension: 60 x 40 x 40mm
Adapter Plug: 5.5 2.1 port
Can Engrave: MDF/Balsa/Paper/Wood/Fabric/Plastic/Leather/Plywood/Foam Paper/Anodized Aluminum
Can Not Engrave: Metal/Glass/Stone/Ceramics/PCB/Stainless Steel/Reflective Material/ Transparent Material

Technical Parameters
Optical power output: 5.5W~7.5W
Wavelength: 445-450nm
Beam Shape: Dot (Focusable)
Working Voltage: DC 12V
TTL&PWM Modulation: YES, compatible with both TTL & PWM Modulation
Input Voltage: DC12V 3A
PWM/TTL Input: DC3.3V-12V
Input Interface: PH2.0-4Pin (+, -, PWM/TTL, Temperature), 3Pin (+, -, PWM/TTL), 2Pin+2Pin (+, -) + (PWM/TTL, -)
Drive Mode: External ACC
Safe temperature range:<60 degrees Celsius
Module weight: 202g (The lighter the weight, the smaller the move inertia, the better the performance)
Life Time: 10000-20,000 hours

Package Included
1 x Laser Engraving Module
1 x Laser Module Sliding slot
1 x 4 Pin Cable (32cm cable)
1 x NEJE interface tranfer board
1 x 2.5mm L-shaped wrench
1 x 5mm L-shaped wrench
1 x 3pin input cable

Product Specifications

Package Weight
One Package Weight: 0.48kgs / 1.06lb
One Package Size: 16cm * 10cm * 6cm / 6.3inch * 3.94inch * 2.36inch
Qty per Carton: 50
Carton Weight: 22.00kgs / 48.50lb
Carton Size: 52cm * 34cm * 32cm / 20.47inch * 13.39inch * 12.6inch
Loading Container: 20GP: 471 cartons * 50 pcs = 23550 pcs, 40HQ: 1094 cartons * 50 pcs = 54700 pcs
